The first transmission is usually a CQ call. Frequencyġ5 meters (most activity found 10 kHz lower) The 7 MHz band is much wider in region 2 (the Americas), thus 7.080 is added for that region.

Ham radio deluxe setup templates software#

In most software packages, you can click on or move a marker to a signal to begin decoding the transmission. If all station setup is correct, you will see something like this: Most packages will have a "waterfall" display where you will see all the signals from the receiver. It is then up to the software, not the radio, what signal(s) to decode.įire up your favorite your favorite PSK31 software. Your will not have to change frequencies after that, since PSK31 signals are so narrow (31 Hz), all the transmissions will be picked up by the receiver without changing frequencies. Make sure your radio is set to SSB mode on the upper sideband (USB).

Ham radio deluxe setup templates full#

Next, tune your radio to a common PSK31 frequency two are 7.070 MHz and 14.070 MHz (see a full list of frequencies below). If you do contact someone with a messy signal, do not give them an automated (macro) signal report of 599 – an easy 595 will let them know to adjust their audio drive.

If the audio level is too high, the ALC controls in the transmitter will kick in, and the result will be a distorted PSK31 signal (splatter). Adjust the audio level until the ALC meter always reads at 0. most PSK31 software packages have a testing / tuning feature for this purpose.Īnother thing to watch is the ALC (automatic leveling control) meter on the radio. This will prevent damage to the transmitter and guard against messy, distorted signals. The first, and most important, step before operating any station is making sure to tune the transmitter.

Ham radio deluxe setup templates install#

Setup / Install Soundcard Interface or Cable.

If the radio's CAT port is already connected to the computer, Ham Radio Deluxe and its multimode software, Digital Master 780, will send the keying command via the CAT connection. The software suite, Ham Radio Deluxe, can utilize this approach. It is plug-and-play compatible with minimal setup required.Īnother option lies in software based keying. This device is an external soundcard that connects to the computer via USB and to my Yaesu FT-857D radio via its data port. My personal favorite is the SignaLink USB from TigerTronics. Some interfaces contain external soundcards themselves, allowing extra flexibility in soundcard setup. These interfaces connect to the computer and key the transmitter whenever an audio tone is present. It might simply be an audio cable with a radio with VOX capabilities, or it might be a specialized external interface. Therefore some form of soundcard interface may be used. PSK31 software will output audio to the PC's soundcard to send a transmission, however a mechanism must exits for keying the radio to transmit an RF signal, as well as link the audio tone to the radio's audio input. Be sure to check our Software Reviews section to see some of the available packages. All PSK31 software has the basic ability to send and receive PSK31 signals. Software for PSK31 is abundant, so the choice of software packages depends largely on personal preference, as will as system requirements.

Ham radio deluxe setup templates Pc#

As a rule, a faster CPU and more memory are desired, however PSK31 will work on virtually any PC equipped with an internal or external soundcard.

The only major requirement for the computer used to send and receive the PSK31 signals is that it contain a soundcard. Obviously, the better the transceiver and antenna, the better performance will be achieved, however PSK31 performance is often virtually the same on both low-end and high-end equipment. The same is true of the antenna, as PSk31 will function with a few watts and a wire antenna.

A basic PSK31 station should consist of the following components:
